Key research themes
1. How can structural analysis methods advance the understanding and seismic assessment of masonry vaults?
This research theme investigates analytical, numerical, and experimental methodologies to understand the mechanical behavior and collapse mechanisms of masonry vaults, particularly focusing on seismic vulnerability assessment and improved modeling techniques. It matters because masonry vaults are significant cultural heritage elements with intricate structural responses, especially under seismic loads, and accurate analysis supports preservation and retrofitting efforts.
Key finding: Proposed a simplified analytical model incorporating the tensile strength of masonry to accurately predict the seismic collapse of slender masonry barrel vaults, overcoming limitations of classical no-tension assumptions;... Read more
Key finding: Developed a nonlinear modeling approach introducing crack identification in two unique Apulian vault types ('volta a spigoli' and 'volta a squadro'), addressing their novel geometries; provided incremental analysis under... Read more
Key finding: Applied a generalized thrust network analysis (GTNA) framework under Heyman's assumptions to verify minimum-thrust and minimum-thickness configurations of a triangular parabolic jewel vault originally designed by Musmeci,... Read more
Key finding: Introduced a force density method-based funicular analysis for curved masonry structures that explicitly integrates stereotomy of voussoirs, limited compressive strength, and finite interface friction; formulated local... Read more
Key finding: Though this paper is not included in the provided set, the related theme suggests that comprehensive experimental campaigns combined with simplified modeling are critical to calibrate and validate numerical seismic analyses... Read more
2. What are the historical construction techniques, geometry, and typologies of masonry vaults, and how do they influence current architectural conservation and design?
This research theme focuses on the typologies, geometric analysis, and construction methods of masonry vaults across historical contexts—from Mediterranean Roman slices vaults to Gothic cross vaults and brick vaults by slices—providing essential knowledge to inform preservation, reconstruction, and adaptation in modern architecture.
Key finding: Through high-precision photogrammetric 3D modeling, the study elucidates the constructive configuration and geometric intricacies of a 5th-century rectangular sail vault built with brick slices, revealing a unique solution to... Read more
Key finding: Conducted an accurate photogrammetric survey to uncover the composite geometric structure of a rare Roman brick groin vault by slices, distinguishing cylindrical and rounded vault segments and confirming that brick... Read more
Key finding: Reviewed the evolution of cross vault forms and sizing rules from Roman to Gothic times and integrated historical 'rules of thumb' with modern limit analysis methods, highlighting the coexistence of empirical geometrical... Read more
Key finding: Using 3D laser scanning and photogrammetry, the study documents a significant collection of 13th-century Spanish brick vaults built without formwork or precise geometric control; findings show that the geometry of severies... Read more
Key finding: Analyzed construction and structural behavior of mid-13th-century ribbed cross vaults in Western Greece, evidencing an efficient but comparatively conservative adaptation of Gothic vault technology influenced by local... Read more
3. How do seismic behavior and retrofitting strategies affect the preservation and performance of masonry vaulted structures?
The focus here is on understanding the seismic response of confined masonry vaults and traditional masonry vaults in historic cities, identifying vulnerabilities and strengths inherent in different vault typologies and construction methods, and evaluating experimental evidence and retrofitting techniques to enhance seismic resilience of masonry heritage buildings.
Key finding: Combining field surveys with Abaqus finite element seismic simulations using real earthquake data, this study identified 19 vaults with varied typologies in Masouleh, Iran; results show that 78% have good structural... Read more
Key finding: Through experimental modeling and incremental dynamic analyses, the study demonstrated that the Karbandi intersecting arch system in historic Iranian buildings effectively suppresses tension regions, improving seismic... Read more
Key finding: Reviewed extensive experimental research confirming that confined masonry (CM) systems, featuring masonry panels confined by reinforced concrete tie-columns and beams, exhibit superior seismic performance compared to... Read more
Key finding: Identified gaps in standardized design for confined masonry due to variability in materials and construction worldwide, emphasizing the need for harmonized experimental, numerical, and design code developments to ensure safe,... Read more
Key finding: The application of GTNA to assess static safety extends to seismic considerations by determining minimum-thrust states under self-weight, a foundational step before dynamic analyses, suggesting the method's utility in... Read more
