Within the confines of this study, seismic soil liquefaction triggering potential of a dam foundation
is assessed within an integrated probabilistic seismic hazard assessment framework. More
specifically, the scheme presented hereby directly integrates effective stress-based seismic soil
liquefaction triggering assessment with seismic hazard analysis framework, supported by an
illustrative case. The proposed methodology successively, i) processes the discrete stages of
probabilistic seismic hazard workflow upon seismic source characterization, ii) numerically
develops the target elastic acceleration response spectra for typical rock sites, covering all the
scenario bins that are re-grouped with respect to earthquake magnitude and distance, iii) matches
the strong ground motion records selected from a database with the target response spectra for
every defined bin, and iv) performs 2-D equivalent linear seismic response analyses of a 56 m high
earthfill dam founded on 24 m thick alluvial deposits. Results of seismic response analyses are
presented in the form of annual probability of excess pore pressure ratios and lateral deformations
exceeding certain threshold values. For the purpose of assessing the safety of the dam slopes, φ-c
reduction-based slope stability analyses were also performed for post liquefaction conditions As
the concluding remark, it is believed that the proposed probabilistic seismic performance
assessment methodology which incorporates both φ-c reduction-based failure probabilities and
seismic soil liquefaction-induced deformation potentials, provides dam engineers to rationally
quantify the level of confidence with their decisions regarding if costly mitigation of dam
foundation soils against seismic soil liquefaction triggering hazard and induced risks is necessary.
Keywords: Seismic hazard, liquefaction, earthfill dams, dynamic analysis
INTRODUCTION
