NASA Technical Memorandum 81662, 1981
by Phillip R. Meng, W.J. Rice, Harold J. Schock
44 pages

Engine: Mazda 12A

> Content ...
> Summary  3
> Statement of problem  5
> Equipment + test procedure  6
> Definition + basic equations  8
> Real time IMEP measurement system  10
> Results + discussion  15
> Summary + conclusions  17
> Appendix A - Correlator circuit description  19
  » Error averaging  21
  » Power supply  24
  » Calibration  24
> References  26
> Tables  28
> Figures  31

german keywords: Wankelmotor / Kreiskolbenmotor
English Keywords: Wankel Engine / Wankel Rotary Engine / Rotary Piston Engine / Rotary Combustion Engine
