Designing and constructing a working chassis is vital to compete in the Shell Eco-marathon
competition. The suspension team is responsible for the design and feasibility of the suspension
system and its components. The powertrain is responsible for the design and uniting electrical
systems of the car. Front-end loading plays a critical part in a major project, although to check
the dimensions and performance of each component, a 3-D model was created for each part
using the software SolidWorks®️ was used to check the dimensions and performance for each
piece. SolidWorks®️ is a capable program for large scale assemblies with file extensions that can
often carry to other programs such as Autodesk®️ and CREO®️. By replicating a 3-D model of
each system in SolidWorks®️ before purchasing individual components improved the overall
attachment of the parts connected to the frame. The reason being that measurements and certain
dimensions were noted on the modeling software to locate and fit each individual component to
the designed frame. This helped with time management since the attachment was already
projected before the arrival of components.
Managing a project requires not only the specialist (engineer) but also the manager who follows
the budget and effectiveness of purchases. Supply chain logistics requires cost analysis whether
to outsource or make in house. It also encompasses the transportation and delivery of materials
and parts to where they are needed most. Mangers then control and advise workflow so the
project stays on schedule and firefighting, the process of excess relocation of resources, is
avoided. Every group member in needs both qualities so work is continuing to improve and each
member master certain small portions of the project bring the project together during meetings.
