Range extender electric vehicles

Der computergestützte Entwurf neuer elektrischer Maschinen verkürzt die notwendigen Entwicklungszeiten deutlich. Numerische Verfahren ermöglichen die Berechnung komplizierter, wirklichkeitsnaher Maschinenmodelle. Unter Einbeziehung nichtlinearer Materialeigenschaften ist die exakte Modellierung dynamischer Vorgänge sowie die schnelle Optimierung der Maschinendaten entsprechend der jeweiligen Zielparameter möglich. Somit können auch bei kleinen zu fertigenden Stückzahlen genau auf die jeweilige Anwendung zugeschnittene Antriebssysteme mit vertretbarem Aufwand entwickelt werden. Der in dieser Arbeit untersuchte Permanent-Magnet-Motor (PMM) ist eine mehrpolige Sonderbauform der permanentmagneterregten Synchronmaschine, der als drehzahlvariabler, getriebeloser Direktantrieb eingesetzt wird. Er hat einen guten Wirkungsgrad und ist in der Lage, sehr große Drehmomente pro Volumeneinheit bei geringer Drehzahl abzugeben. Die erarbeiteten Maschinenmodelle dienen als Grundlage für weiterführen...

Bei PKW-Abgasturboladern mit Schwimmbuchsenlagern können in einem breiten Betriebsdrehzahlbereich gleitlagertypische Oil-Whirl-und Oil-Whip-Effekte auftreten. Zu deren Beschreibung werden in diesem Beitrag die Modellierung und der Modellabgleich des Rotors eines Abgasturboladers vorgestellt. Zur Modellierung des Rotors werden im Sinne eines Ritz-Verfahrens die ersten vier Eigenformen (zwei Starrkörper-und zwei Biegeeigenformen) des ungefesselten Rotors verwendet. Mit einer experimentellen Modalanalyse am freien Rotor wird das Rotormodell abgesichert. Die Fluidfilme in den Schwimmbuchsenlagern werden mit Finiten Volumen modelliert und das Rotorgehäuse wird als starr und unverschieblich angesetzt. Für die Modellanpassung veränderbare Parameter sind die Lagergeometrie, die unterschiedlichen Ölviskositäten im inneren und im äußeren Schmierfilm sowie die Eigenfrequenzen des Rotormodells. Am Versuchsmodell werden die Rotorbewegung in zwei orthogonale Richtungen einer Ebene am Verdichterrad und die Schwimmbuchsendrehzahl in Abhängigkeit von der Rotordrehzahl gemessen. Zur Messung der Schwimmbuchsendrehzahl wird das Turboladergehäuse mittels 3-D-Druck transparent ausgeführt. Dadurch können die Schwimmbuchsen während des Betriebes mit einer Hochgeschwindigkeitskamera optisch erfasst werden. Die Auswertung der Hochgeschwindigkeitsbilder liefert die aktuelle Buchsendrehzahl. Zum Abgleich des numerischen Modells werden die Schwimmbuchsendrehzahl und die Amplituden und Frequenzen der Rotorschwingungen in Abhängigkeit von der Rotordrehzahl herangezogen. Für den Modellabgleich werden verschiedene Versuche durchgeführt: Bei ansteigender und abfallender Rotordrehzahl wird in einem Versuch das Konstanttonphänomen, eine subsynchrone Bewegungsform mit nahezu konstanter Frequenz, erzwungen. In einem zweiten und dritten Versuch wird ein Oil-Whirl im inneren Schmierfilm erzeugt. Nach Anpassung der Modellparameter (Lager-und Schwimmbuchsengeometrie, Ölfilmviskositäten, Rotoreigenschaften) konnte eine sehr gute Übereinstimmung der gemessenen und der berechneten Zeitverläufe der Rotorbewegung und der Schwimmbuchsendrehzahl beobachtet werden.

Kurzfassung Bei PKW-Abgasturboladern mit Schwimmbuchsenlagern könne n i einem breiten Betriebsdrehzahlbereich gleitlagertypische Oil-Whirlund Oil-Whip-Effekte auft reten. Zu deren Beschreibung werden in diesem Beitrag die Modellierung und der Modellabgleich des Rotors eines Ab gasturboladers vorgestellt. Zur Modellierung des Rotors werden im Sinne eines Ritz-Verf ahrens die ersten vier Eigenformen (zwei Starrkörperund zwei Biegeeigenformen) des ungefesselte n Rotors verwendet. Mit einer experimentellen Modalanalyse am freien Rotor wird das Rotormodell abgesichert. D ie Fluidfilme in den Schwimmbuchsenlagern werden mit Finiten Volumen modelliert und das Rotorgehäuse wird al s starr und unverschieblich angesetzt. Für die Modellanpassung veränderbare Parameter sind die Lagergeome trie, die unterschiedlichen Ölviskositäten im inneren und im äußeren Schmierfilm sowie die Eigenfrequenzen des Rot orm dells. Am Versuchsmodell werden die Rotorbewegung in zwei orthogo nale Richtungen einer Eb...

Hydrogen has proven itself to be a great source of energy due to its physical characteristics and its high availability. One way to use the energy inside hydrogen is the fuel cell. But inside a moving car, hydrogen storage tank existence requires high precautions and present many increasing risks; so our idea takes the theory of HHO (hydrogen generator) to separate hydrogen and then utilize a fuel cell to produce clean source of energy. This produced electrical energy will be used in operating an electrically powered car, and in charging the HHO cell. Electrically powered cars as an aim draws us to this work, the first part for producing hydrogen gas from water, the design parameters of the electrochemical cell, and the reached findings will be presented. It was found that stainless steel 304 was more convenient for the electrode materials compared with other metals. The amount of hydrogen evolved was confirmed by pop-sound test. The fuel cells was settled to be the most effective w...

Elementare Betrachtungen zum stationären Magnetfeld 19.1 Magnetische Kraftwirkungen und das B-Feldes Wie mit dem Vorhandensein elektrischer Ladungen immer ein elektrisches Feld verbunden ist, so tritt immer ein magnetisches Feld auf, wenn elektrische Ströme fließen, wenn sich also elektrische Ladungen bewegen. Ein stationäres magnetisches Feld entsteht, wenn es sich um Gleichstrom handelt, der also hinsichtlich der Stromdichte J bzw. des Stromes I zeitkonstant ist. Daher sprechen wir in diesem Fall von Stationarität. Das magnetische Feld kann wie das elektrische durch Feldlinien veranschaulicht werden. Von dem Verlauf dieser Linien geben die bekannten, erstmals im Jahre 1821 von Seebeck [21] durchgeführten Versuche mit Eisenspänen eine Vorstellung. Auf langgestreckten Eisenspänen oder auf Magneten werden im magnetischen Feld mechanische Kräfte ausgeübt, die die Eisenspäne in eine bestimmte Richtung zu drehen versuchen. Dadurch wird die Feldlinienrichtung an jeder Stelle des B-Feldes definiert, das nach Abschnitt 18 die Kraftwirkungen des magnetischen Feldes charakterisiert. Diese Feldlinien bezeichnet man als magnetische Induktionslinien, magnetische Feldlinien oder hier als B-Feldlinien. Abbildung 19.1. B-Feldlinien einer Drahtspule Wichtige Anwendungen dieser Vorstellung sind magnetische Speichermedien wie Magnetbänder, bei denen man durch einäußeres Magnetfeld die lang

Diese Arbeit beschäftigt sich mit dem Entwurf und der experimentellen Untersuchung zweier wirkungsgradoptimierter Asynchronmaschinen für eine Nennleistung von 20 kW und eine Nenndrehzahl von 30.000 min-1. Der Schwerpunkt der Untersuchungen liegt auf der Quantifizierung des Einflusses des verwendeten magnetisch aktiven Materials. Es kommen zum einen ein hoch-siliziertes Blech (M270-35A) und zum anderen eine Kobalt-Eisen-Legierung (Vacoflux 50) zum Einsatz. Im ersten Abschnitt der Arbeit wird abgeleitet, wie sich Leistung und Verluste mit zunehmender Drehzahl verhalten und wo technologische Grenzen schnelldrehender Maschinen liegen. Im Anschluss werden zur detaillierten Berücksichtigung der Materialeigenschaften während des Maschinenentwurfs kombiniert analytisch-numerische Berechnungsmethoden entwickelt. Mit Hilfe dieser Methoden lassen sich Maschinenparameter und Feldamplituden auch für analytisch schwer erfassbare Fälle, wie geschlossene Rotornuten, mit guter Genauigkeit vorausberechnen. Ergänzend wird ein einfach parametrierbares Modell des Rotors zur Berechnung der Eigenfrequenzen eingeführt. Die Erwärmung wird mit Hilfe eines thermischen Netzwerkmodells bestimmt. Das Vorgehen bei der Variantenberechnung zur Ermittlung der wirkungsgradoptimalen Maschine wird ausführlich erläutert. Beide Maschinen wurden im "back-to-back" Verfahren experimentell untersucht. Die Gültigkeit der Berechnungsverfahren und die Performance der verwendeten Materialien werden anhand von Leerlauf-und Lastmessungen, Schwingungsmessungen und eines Erwärmungslaufes überprüft. Ergänzend wurden Geräuschfrequenzmessungen durchgeführt.

An approach for controlling a hydrostatic dynamometer for the hardware-in-the-loop (HIL) testing of hybrid vehicles is proposed and experimentally evaluated. The hydrostatic dynamometer, which is capable of absorbing and regenerating power, was specifically designed and built in-house to evaluate the fuel economy and control strategy of a hydraulic hybrid vehicle being developed. Unlike a chassis dynamometer whose inertia is similar to the inertia of the vehicle being tested, the inertia of this hydrostatic dynamometer is only 3% of the actual vehicle. While this makes the system low cost, compact, and flexible for testing vehicles with different weights and drag characteristics, control challenges result. In particular, the dynamometer must apply, in addition to the torques to mimic the wind and road drag, also the torques to mimic the acceleration and deceleration of the missing inertia. To avoid estimating the acceleration and deceleration, which would be a noncausal operation, a...

The purpose of this paper is to reveal the effect of fuel injection pressure on the power and torque of a diesel engine. The research method used is the experimental method. Pressure variations of 110 kg/cm 2 , 120 kg/cm 2 and 130 kg/cm 2 were applied to a 1981 Chevrolet LUV diesel car. From the experimental results of research conducted at the Automotive Engineering Vehicle Workshop, Faculty of Engineering, Universitas Negeri Padang, it was found that, at a standard pressure of 120 kg/cm 2 obtained an average car power of 29.6 kW at 4470 RPM and 81.65 Nm of torque at 2455 RPM. When the injector pressure is reduced by 110 kg/cm 2 , engine power decreases by 17.1% and torque decreases by 16.2%. When the injector pressure is increased to 130 kg/cm2, there is an increase in engine power by 4.05% and a decrease in torque by 14.89%.

Changing market requirements, pressure to minimize production costs, competition, but also legislative restrictions have an impact on a number of areas, not excluding the automotive industry. Currently, development trends are moving towards the application of advanced technological solutions and materials, with the aim to reduce vehicle's weight, increase their strength and safety, and at the same time reduce the emission of vehicles. The Shell Eco Marathon competition is an excellent platform for the implementation of these activities. The main goal of the competition is to support the creative invention of research teams and bring innovative ideas and technical solutions. The scientific article focuses on a detailed analysis of development steps in the construction of experimental vehicles. The results of the research were presented at a competition in London 2019 with successful achievement. This work is a contribution to the design and aerodynamic optimization of the body and at the same time brings new ideas and structural elements to improve the production power unit.

Hydrogen has proven itself to be a great source of energy due to its physical characteristics and its high availability. One way to use the energy inside hydrogen is the fuel cell. But inside a moving car, hydrogen storage tank existence requires high precautions and present many increasing risks; so our idea takes the theory of HHO (hydrogen generator) to separate hydrogen and then utilize a fuel cell to produce clean source of energy. This produced electrical energy will be used in operating an electrically powered car, and in charging the HHO cell. Electrically powered cars as an aim draws us to this work, the first part for producing hydrogen gas from water, the design parameters of the electrochemical cell, and the reached findings will be presented. It was found that stainless steel 304 was more convenient for the electrode materials compared with other metals. The amount of hydrogen evolved was confirmed by pop-sound test. The fuel cells was settled to be the most effective w...

Air conditioning in automobiles is done by air conditioning compressor driven by the engine. The engine exerts a specific power to run air conditioning system. During running, fuel consumption, noise and vibration increase. Most of gasoline automobiles in Turkey have used Liquefied Petroleum Gas (LPG) as an alternative fuel. In this study, the effect of use of Air Conditioner (AC) on engine vibration in gasoline car engines are experimentally investigated. According to the experiment results, it is observed that the use of AC while running on LPG decreases the engine vibration at the revolution speeds of 800, 2000, 3000 and 5000 rev/min whereas the use of AC while running on gasoline decreases the engine vibration at the revolution speeds of 2000, 3000 and 4000 rev/min. In addition to that, when the AC is on, the levels of vibration increase in the engine while running on LPG and gasoline are observed to be linear and nonlinear with the increase in the idle revolution speeds, respectively. Accordingly, it can be concluded that the car engine while using LPG is running more stably compared to that while using gasoline.

Zusammenfassung Der Einsatz elektrischer Einzelradantriebe in Kraftfahrzeugen eröffnet auf Grund der Möglichkeit der schnellen und genauen radindividuellen Stellung positiver und negativer Drehmomente neue Potenziale für die Fahrdynamikregelung. Hierdurch wird eine Regelung des Reifenlängsschlupfes an jedem Rad mit hoher Dynamik und Genauigkeit sowie eine höhere Energieeffizienz ermöglicht, die mit konventionellen Eingriffen des Bremssystems nicht umsetzbar ist. Damit eine darauf aufbauende Regelung der Fahrzeugdynamik diese Vorteile konsequent ausnutzen kann, wird in diesem Beitrag ein hierarchisches Konzept zur Fahrdynamikregelung vorgestellt, das eine Unterteilung der Beobachtungs- und Regelungsstruktur auf Rad- und Fahrzeugebene vorsieht.

Compilation of articles on motor-fan.jp in 2023
36 pages

1. Its name is "8C type"! Mazda Rotary is back! MX-30 PHEV model "e-SKYACTIV R-EV"      Published on 2023/01/13      2 pages
  Page 2
2. Mazda's new rotary "Model 8C" / How is 13A related to 16X?
      Published Date 2023/04/15      Kota Sera      4 pages
  Page 4
3. The Mazda 8C Rotary is a "new rotary engine that pursues the ideal" newly developed using the  technology cultivated at SKYACTIV [Internal Combustion Engine Super Basic Course]      Published 2023/09/14
      Kota Sera      11 pages
  Page 8
4. A special engine that only Mazda can build, the 8C rotary, is thus built
      Published 2023/10/08      Kota Sera      7 pages
  Page 19
5. New Generation Rotary: Mazda 8C, Complete Explanation (excerpt only)
      Motor Fan Illustrated Vol.204      Release Date: 15. September 2023
      Kota Sera      11 pages
  Page 26

Numeric values are not necessarily correct - translations by browser have included a lot of confusions, e.g. like "2023-rotor ... MX-1 ...
in 30". And price tags have been irritating using e.g. "<>" ...

german keywords: Wankelmotor / Kreiskolbenmotor
English Keywords: Wankel Engine / Wankel Rotary Engine / Rotary Piston Engine / Rotary Combustion Engine
