Key research themes
1. How can modeling parameters and casing treatments mitigate surge and stall phenomena in axial compressors?
This theme focuses on understanding and controlling flow instabilities, particularly surge and stall, in axial compressors through modeling of dynamic parameters and innovative casing treatments. Surge and stall limit compressor stability and operational range, causing mechanical stresses and efficiency losses. By investigating the specific geometric and operational variables influencing these phenomena, as well as active and passive flow control methods such as vaned recessed casing treatments and recirculation channels, researchers seek to enhance compressor stability and performance.
Key finding: Using a lumped volume Moore-Greitzer model, this numerical study systematically dissected the influence of non-dimensional groups and identified key geometric (e.g., compressor duct length, plenum volume) and operational... Read more
Key finding: Numerical simulations revealed that modifying the shape of vanes in vaned recessed casing treatments (using fully curved guide vanes) and shaping the shroud top with a circular curve can substantially improve stall margin by... Read more
Key finding: Computational fluid dynamics (CFD) analysis of an axisymmetric recirculation channel casing treatment on NASA rotor 37 demonstrated that strategically positioning the channel at 18.2% axial chord from the blade tip leading... Read more
Key finding: Steady RANS simulations showed that a passive axisymmetric recirculation channel self-adapts flow control according to rotor load, reducing detrimental tip leakage flow and blade tip incidence angle. The channel’s... Read more
2. How does inlet guide vane (IGV) angle optimization affect subsonic axial compressor performance across varying operational and climatic conditions?
Inlet guide vanes (IGVs) influence flow incidence angles and velocity profiles upstream of the compressor rotor, thereby impacting aerodynamic performance, pressure ratio, and efficiency. Optimizing IGV stagger angles under different climatic conditions is critical for maintaining compressor performance away from design point operation. This theme explores the aerodynamic and thermodynamic effects of IGV angle variation through numerical simulation and blade design optimization to enhance performance stability over a range of operating scenarios.
Key finding: CFD simulations combined with blade design tools demonstrated that varying the IGV stagger angle between 15°, 30°, and 45° significantly affects total pressure loss coefficient, pressure ratio, and volume flow under different... Read more
Key finding: Unsteady RANS simulations at design and near-stall conditions of a low-pressure axial compressor stage highlighted the critical influence of inlet guide vane (IGV) settings on rotor-stator interaction and secondary flow... Read more
3. What are the challenges and optimization opportunities for positive displacement compressors such as screw compressors, particularly in relation to leakage, flow modeling, and multiphase flow handling?
Positive displacement compressors like screw compressors face unique challenges including internal leakage, heat transfer, and multiphase flow effects that influence efficiency and durability. This research area investigates structural geometry optimization, CFD modeling of tooth profiles, and the characterization of multiphase flow interactions at compressor suction to improve sealing, reduce energy losses, and extend applicability in industrial settings.
Key finding: Provided a comprehensive synthesis of recent advancements and challenges in positive displacement compressors, detailing performance impacts due to leakages, heat transfer inefficiencies, valve dynamics, and lubrication... Read more
Key finding: Through detailed CFD simulation of various screw compressor tooth profiles, this study quantified the influence of clearance and tooth geometry on leakage flow patterns, pressure distribution, and volumetric efficiency. The... Read more
Key finding: Initial experimental and CFD studies mapped multiphase flow distributions at the suction domain of twin-screw compressors. Findings revealed that simplified suction domain CFD models can accurately capture flow features,... Read more
