Comparison of the root water uptake term of four simulation models

Profile image of Marius HeinenMarius Heinen

2011, Atmospheric Chemistry and Physics

Abstract

Willigen P. de, J.C. van Dam, M. Javaux and M. Heinen, 2011. Comparison of the root water uptake term of four simulation models. Wageningen, Alterra, Alterrareport 2206. 66 pp.; 24 fig.; 8 tab.; 31 ref.

Figures (41)
References for description an applications of the models. Table 1 We particularly investigate how the four models cope with hydraulic lift compensation mechanisms and effect of soil on uptake. With hydraulic lift we mean root water excretion, when the xylem pressure heads exceeds the pressure head at the root-soil interface. So hydraulic lift may also denote downward movement of water by the root system. Each of these models also differ by its intrinsic complexity. The importance of such a complexity against modeling performances is also assessed in this report. For the comparison three scenarios will be considered. In the first one we check whether the models concerned do give similar results with respect to the basic processes of soil water flow. The other two scenarios specifically aim at comparing the respective water uptake routines. In recent years the increasing computational capacity and development of microscopic measurement techniques for root water uptake create avenues for an even more detailed physical based modeling approach. A clear example is the RSWMS model (Javaux et al., 2008) which accommodates 3-dimensional rooting patterns with detailed water movement. RSWMS simulates 3-dimensional soil water flow, flow towards the roots, and radial and longitudinal flow inside the root system. This creates new research possibilities on the important feedback mechanisms occurring in the rhizosphere when soil moisture becomes limiting. In this report, we show the performance of various modeling concepts covering a broad range of assumptions for well-defined drought situations. Four models were involved in the comparison in the comparison, these are oiven hy their acrgnyme SWAP-macron SWAP-micro FIISSIM2 and RSWMS Table 1 oivec references for the
References for description an applications of the models. Table 1 We particularly investigate how the four models cope with hydraulic lift compensation mechanisms and effect of soil on uptake. With hydraulic lift we mean root water excretion, when the xylem pressure heads exceeds the pressure head at the root-soil interface. So hydraulic lift may also denote downward movement of water by the root system. Each of these models also differ by its intrinsic complexity. The importance of such a complexity against modeling performances is also assessed in this report. For the comparison three scenarios will be considered. In the first one we check whether the models concerned do give similar results with respect to the basic processes of soil water flow. The other two scenarios specifically aim at comparing the respective water uptake routines. In recent years the increasing computational capacity and development of microscopic measurement techniques for root water uptake create avenues for an even more detailed physical based modeling approach. A clear example is the RSWMS model (Javaux et al., 2008) which accommodates 3-dimensional rooting patterns with detailed water movement. RSWMS simulates 3-dimensional soil water flow, flow towards the roots, and radial and longitudinal flow inside the root system. This creates new research possibilities on the important feedback mechanisms occurring in the rhizosphere when soil moisture becomes limiting. In this report, we show the performance of various modeling concepts covering a broad range of assumptions for well-defined drought situations. Four models were involved in the comparison in the comparison, these are oiven hy their acrgnyme SWAP-macron SWAP-micro FIISSIM2 and RSWMS Table 1 oivec references for the
Variables and parameters considered in the water uptake routine of the different models Table 2
Variables and parameters considered in the water uptake routine of the different models Table 2
Reduction coefficient (a) as a function of pressure head (h) as used in SWAP-macro. The uptake rate is expressed in cm? cm? d?. The relation between / and a is shown in Figure 1
Reduction coefficient (a) as a function of pressure head (h) as used in SWAP-macro. The uptake rate is expressed in cm? cm? d?. The relation between / and a is shown in Figure 1
SO w,,iS almost proportional to root length density as the numerator of the RHS of Eq. (19) changes much aster with change in Z,, than the denominator. The highest possible uptake rate occurs when the pressure head at the root surface is that at wilting point. n that case the matric flux potential at the root surface is then zero by definition, see Eq. (10). If the corresponding uptake rate is greater than the required uptake rate the actual uptake rate is equal to the required uptake rate, else it equals the highest possible uptake rate. So the actual uptake rate of a single ayer can be formulated as:
SO w,,iS almost proportional to root length density as the numerator of the RHS of Eq. (19) changes much aster with change in Z,, than the denominator. The highest possible uptake rate occurs when the pressure head at the root surface is that at wilting point. n that case the matric flux potential at the root surface is then zero by definition, see Eq. (10). If the corresponding uptake rate is greater than the required uptake rate the actual uptake rate is equal to the required uptake rate, else it equals the highest possible uptake rate. So the actual uptake rate of a single ayer can be formulated as:
As mentioned in the context of Eq. (17) R, >> R,,s0 p° >>1, so that Note the similarity between Eq. (30) and Eq. (19). The constant in the second term of the denominator on the RHS of Eq. (19) is — a tale? = -1.55, almost the same as -1.5 in Eq. (30). The uptake rate can be made explicit from Eq. (27) yielding:
As mentioned in the context of Eq. (17) R, >> R,,s0 p° >>1, so that Note the similarity between Eq. (30) and Eq. (19). The constant in the second term of the denominator on the RHS of Eq. (19) is — a tale? = -1.55, almost the same as -1.5 in Eq. (30). The uptake rate can be made explicit from Eq. (27) yielding:
Equation (34) states that in the path soil - root surface - xylem there is no accumulation of water, Eq. (35) gives the relation between leaf and root potential, and Eq. (36) states that transport into the root equals actual transpiration. Because of the non-linearity of Eqs. (35) and (36) these equations have to be solved by iteration for the three unknowns /, (from which ®, follows) /,and #, for a given bulk pressure head /in the soil layer (from which ® follows). ey EE pr: fe PES eel | hd en Se ee eee! Med agate oceans cr gm | ceerren—er The calculations for a multilayer system proceed along the same lines. Details can be found in Appendix 1. Where #, is the leaf water pressure head (cm), /, is the root water pressure head (cm), 7, is the actual transpiration rate (cm d*), and Z, is the conductance in the path root to leaf (d). Details are found in Appendix |. The actual transpiration is a function of the potential transpiration and the leaf water potential, we used the approach of Campbell (1985, 1991) proposed, i-e.:
Equation (34) states that in the path soil - root surface - xylem there is no accumulation of water, Eq. (35) gives the relation between leaf and root potential, and Eq. (36) states that transport into the root equals actual transpiration. Because of the non-linearity of Eqs. (35) and (36) these equations have to be solved by iteration for the three unknowns /, (from which ®, follows) /,and #, for a given bulk pressure head /in the soil layer (from which ® follows). ey EE pr: fe PES eel | hd en Se ee eee! Med agate oceans cr gm | ceerren—er The calculations for a multilayer system proceed along the same lines. Details can be found in Appendix 1. Where #, is the leaf water pressure head (cm), /, is the root water pressure head (cm), 7, is the actual transpiration rate (cm d*), and Z, is the conductance in the path root to leaf (d). Details are found in Appendix |. The actual transpiration is a function of the potential transpiration and the leaf water potential, we used the approach of Campbell (1985, 1991) proposed, i-e.:
Relative transpiration as a function of plant water potential (Eq. (33). Parameters: q = 0.7, hy, 12 = 16600 cm. Summarizing: the FUSSIM2 water uptake routine does not merely take the soil properties into account, but also the plant properties as radial conductance, and plant conductance. The actual transpiration is a function of the leaf water potential.
Relative transpiration as a function of plant water potential (Eq. (33). Parameters: q = 0.7, hy, 12 = 16600 cm. Summarizing: the FUSSIM2 water uptake routine does not merely take the soil properties into account, but also the plant properties as radial conductance, and plant conductance. The actual transpiration is a function of the leaf water potential.
Domain and resolution details of the four models.
Domain and resolution details of the four models.
Mualem - van Genuchten parameters for three soils of the Dutch Staring series (Wosten et al., 2001)
Mualem - van Genuchten parameters for three soils of the Dutch Staring series (Wosten et al., 2001)
Architecture of a 45-d old Maize root system.
Architecture of a 45-d old Maize root system.
$2: The second root water uptake scenario is similar to S1, except that 1) precipitation did not occur, and 2) the transpiration during the day was distributed according to a sinusoidal pattern: 00:00 - 06:00, no transpiration; 06:00 - 18:00, transpiration following a (positive) sine curve (in total 4 mm d*); 18:00 - 24:00, no transpiration. This means that at 12:00 the potential transpiration demand is 12.6 mm d?, much larger than the average demand of 4 mm d" (Figure 4).
$2: The second root water uptake scenario is similar to S1, except that 1) precipitation did not occur, and 2) the transpiration during the day was distributed according to a sinusoidal pattern: 00:00 - 06:00, no transpiration; 06:00 - 18:00, transpiration following a (positive) sine curve (in total 4 mm d*); 18:00 - 24:00, no transpiration. This means that at 12:00 the potential transpiration demand is 12.6 mm d?, much larger than the average demand of 4 mm d" (Figure 4).
Model specific inout data with respect to root water extraction. Table 5
Model specific inout data with respect to root water extraction. Table 5
Figure 6 Diftusivity (solid lines) and volumetric water content (broken lines) as a function of absolute pressure head.
Figure 6 Diftusivity (solid lines) and volumetric water content (broken lines) as a function of absolute pressure head.
Scenario Check. Distribution of pressure head with depth at time = 0.5, 1 and 10 days. The lines pertain to FUSSIM2, the squares to SWAP and the triangles to RSWMS for the three soils Zandb3 (a), Kleib1 1 (b) and Leemb13 (c).
Scenario Check. Distribution of pressure head with depth at time = 0.5, 1 and 10 days. The lines pertain to FUSSIM2, the squares to SWAP and the triangles to RSWMS for the three soils Zandb3 (a), Kleib1 1 (b) and Leemb13 (c).
Pressure head distribution as calculated with RSWMS, after a dry spell of 15.5 days with a potential transpiration rate of 4 mm ad The previous two sections presented the different water uptake models in case of a single layer. It is also interesting to see how uptake is distributed over the root system for a given pressure head distribution. The model RSWMS was used to generate the pressure head profiles for the three soils after a dry period of 15.5 days, with a potential transpiration rate of 4 mm d?. This pressure head profile was used to calculate the corresponding water uptake distribution for the four models, employing the parameters given in Table 5. Figure 10 presents the pressure head profile for the three soil types and Figure 11 the computed relative root water uptake from the soil column. Note that only in the case of SWAP-macro the soils pressure head distribution has a direct relation to water uptake distribution. In the other three models the relation is indirect: in case of SWAP-micro via the pressure head at the soil-root interface (PHR), for FUSSIM2 via PHR, the root pressure head (PHX) and radial root resistance, and in RSWMS via PHR, PHX, root radial and axial resistance. The water uptake distribution of FUSSIM2 shows the largest differences between the three soils, which has to do with the fact that here in case of clay and loam hydraulic lift occurred in the upper 10-15 cm. The other models showed a similar pattern of uptake distribution for all three soils, especially in the case of RSWMS.
Pressure head distribution as calculated with RSWMS, after a dry spell of 15.5 days with a potential transpiration rate of 4 mm ad The previous two sections presented the different water uptake models in case of a single layer. It is also interesting to see how uptake is distributed over the root system for a given pressure head distribution. The model RSWMS was used to generate the pressure head profiles for the three soils after a dry period of 15.5 days, with a potential transpiration rate of 4 mm d?. This pressure head profile was used to calculate the corresponding water uptake distribution for the four models, employing the parameters given in Table 5. Figure 10 presents the pressure head profile for the three soil types and Figure 11 the computed relative root water uptake from the soil column. Note that only in the case of SWAP-macro the soils pressure head distribution has a direct relation to water uptake distribution. In the other three models the relation is indirect: in case of SWAP-micro via the pressure head at the soil-root interface (PHR), for FUSSIM2 via PHR, the root pressure head (PHX) and radial root resistance, and in RSWMS via PHR, PHX, root radial and axial resistance. The water uptake distribution of FUSSIM2 shows the largest differences between the three soils, which has to do with the fact that here in case of clay and loam hydraulic lift occurred in the upper 10-15 cm. The other models showed a similar pattern of uptake distribution for all three soils, especially in the case of RSWMS.
Total water uptake rate in cm d! of the models corresponding to the pressure head distribution given in Figure 10. Table 6
Total water uptake rate in cm d! of the models corresponding to the pressure head distribution given in Figure 10. Table 6
Simulated relative root water uptake of the four models, corresponding to the pressure head distribution depicted in Figure 10, root densities depicted in Figure 5 and potential transpiration rate 0.4 cm d!
Simulated relative root water uptake of the four models, corresponding to the pressure head distribution depicted in Figure 10, root densities depicted in Figure 5 and potential transpiration rate 0.4 cm d!
Time of onset of the reduction period and the total transpiration realized in 30 d for the different models in scenario S1. Table 7
Time of onset of the reduction period and the total transpiration realized in 30 d for the different models in scenario S1. Table 7
As Figure 13 fort = 15.5.
As Figure 13 fort = 15.5.
As Figure 13 for t = 30.5 a.
As Figure 13 for t = 30.5 a.
Differences in pressure head at root surface (PHR), in root xylem (PHX) and gradient of pressure head between root surface and xylem (PHX-PHR) between results of RSWMS and FUSSIM2.
Differences in pressure head at root surface (PHR), in root xylem (PHX) and gradient of pressure head between root surface and xylem (PHX-PHR) between results of RSWMS and FUSSIM2.
Figure 17 Relative water uptake as a function of root length density and pressure head at t = 0.5 d (left column) and t = 15 d (right column).
Figure 17 Relative water uptake as a function of root length density and pressure head at t = 0.5 d (left column) and t = 15 d (right column).
Total transpiration (cm) after 15 days in scenario S1 and S2. Table 8
Total transpiration (cm) after 15 days in scenario S1 and S2. Table 8
Time course of cumulative transpiration for S1 (left column) and 82 (right column).
Time course of cumulative transpiration for S1 (left column) and 82 (right column).
Figure 21
Figure 21
Figure 22
Figure 22
a) Pressure head distribution after 10 days for the three cases considered, and b) cumulative transpiration for the three cases considered.
a) Pressure head distribution after 10 days for the three cases considered, and b) cumulative transpiration for the three cases considered.
Relation between the conductance in the path root - leaf for maize and potential transpiration. Data of Zhuang et al. (2001). According to the study of Zhuang et al. (2001) the conductance in a maize plant in the path root - leaf is a function of the potential transpiration (Figure A-1). So the leaf water potential can be calculated as:
Relation between the conductance in the path root - leaf for maize and potential transpiration. Data of Zhuang et al. (2001). According to the study of Zhuang et al. (2001) the conductance in a maize plant in the path root - leaf is a function of the potential transpiration (Figure A-1). So the leaf water potential can be calculated as:
Alterra is part of the international expertise organisation Wageningen UR (University & Research centre). Our mission is ‘To explore the potential of nature to improve the quality of life’. Within Wageningen UR, nine research institutes — both specialised and applied — have joined forces with Wageningen University and Van Hall Larenstein University of Applied Sciences to help answer the most important questions in the domain of healthy food and living environment. With approximately 40 locations (in the Netherlands, Brazil and China), 6,500 members of staff and 10,000 students Wageningen UR is one of the leading organisations in its domain worldwide. The integral approach to problems and the cooperation between the exact sciences and the technological and social disciplines are at the heart of the Wageningen Approach.
Alterra is part of the international expertise organisation Wageningen UR (University & Research centre). Our mission is ‘To explore the potential of nature to improve the quality of life’. Within Wageningen UR, nine research institutes — both specialised and applied — have joined forces with Wageningen University and Van Hall Larenstein University of Applied Sciences to help answer the most important questions in the domain of healthy food and living environment. With approximately 40 locations (in the Netherlands, Brazil and China), 6,500 members of staff and 10,000 students Wageningen UR is one of the leading organisations in its domain worldwide. The integral approach to problems and the cooperation between the exact sciences and the technological and social disciplines are at the heart of the Wageningen Approach.

Related papers

Modeling water uptake by a root system growing in a fixed soil volume
Jorge Luis Blengino Albrieu, Juan Carlos Reginato, Domingo A . Tarzia

Applied Mathematical Modelling, 2014

The water uptake by roots of plants is examined for an ideal situation, with an approximation that resembles plants growing in pots, meaning that the total soil volume is fixed. We propose a coupled water uptake-root growth model. A one-dimensional model for water flux and water uptake by a root system growing uniformly distributed in the soil is presented, and the Van Genuchten model for the transport of water in soil is used. The governing equations are represented by a moving boundary model for which the root length, as a function of time, is prescribed. The solution of the model is obtained by front-fixing and finite element methods. Model predictions for water uptake by a same plant growing in loam, silt and clay soils are obtained and compared. A sensitivity analysis to determine relative effects on water uptake when system parameters are changed is also presented and shows that the model and numerical method proposed are more sensitive to the root growth rate than to the rest of the parameters. This sensitivity decreases along time, reaching its maximum at thirty days. A comparison of this model with a fixed boundary model with and without root growth is also made. The results show qualitative differences from the beginning of the simulations, and quantitative differences after ten days of simulations.

View PDFchevron_right
Simulation of field water uptake by plants using a soil water dependent root extraction function
Piotr Kowalik

Journal of Hydrology, 1976

Water uptake by roots can be represented by adding a volumetric sink term to the continuity equation for soil-water flow. This sink term is often expressed as a product of the difference in pressure head between the soil and the root-soil interface, the hydraulic conductivity of the soil and some empirical root function. Because of the amount of field work and experimental difficulties involved in determining this root function, an attempt was made to describe the sink term with a more simple expression. In this approach the sink term is considered to be a function of the soil-water content, varying with the latter according to the pressure heads generally known to be critical for water uptake by the roots. An implicit finite-difference model was developed and verified with results obtained experimentally in the field from water-balance studies. Although the model does not predict the distribution of soil-water content with depth in very accurate detail, the cumulative effect over the entire depth is properly simulated. Comparison of the results of the simpler model with those of the model of Feddes, Bresler and Neuman, leads to the conclusion that both models yield comparable results.

View PDFchevron_right
Water uptake by plant roots: II–Modelling of water transfer in the soil root-system with explicit account of flow within the root system–Comparison with experiments
Emmanuelle Garrigues

Plant and soil, 2006

Soil water uptake by plant roots results from the complex interplay between plant and soil which modulates and determines transport processes at a range of spatial and temporal scales: at small scales, uptake rates are determined by local soil and root hydraulic properties but, at the plant scale, local processes interact within the root system and are integrated through the hydraulic architecture of the root system and plant transpiration. However, because of the inherent complexity of the root system (both structural and functional), plant roots are commonly account for with synthetic but over-simplifying descriptors, valid at a given spatial scale. In this article, we present a model describing both soil and plant processes involved in water uptake at the scale of the whole root system with explicit account of individual roots. This is achieved through the unifying concepts of root system architecture and hydraulic continuity between the soil and plant. The model is based on a combination of architectural, root system hydraulic and soil water transfer modelling. The model can reproduce qualitatively and quantitatively laboratory experimental data obtained from imaging of water uptake by light transmission (cf. Garrigues et al., Water uptake by plant roots: I-Formation and propagation of a water extraction front in mature root systems as evidenced by 2D light transmission imaging. Plant and soil (2006, this issue) or X-ray imaging for two soil types (a sand/clay mix and a sandy clay loam) and different narrow-leaf lupin root systems (taprooted and fibrous), using independently measured soil-plant parameters. Results of the experiments and modelling reported in this paper concur to show that a water extraction front formed on the root system. This uptake frontÕs spatial extension and propagation were closely related to the local dependence between root and soil hydraulic properties and root axial conductance. Hence, a sharp front formed in the sand/clay mix but was much more attenuated in the sandy loam. Comparison between taprooted and fibrous root systems grown in a sand/clay mix, show that the taprooted architecture induced a more spatially concentrated uptake zone (near the soil surface) with higher flux rates, but with xylem water potential at the base of the root system twice as low than in the fibrous architecture. Modelling provided evidence that hydraulic lift might have occurred when transpiration declined, particularly in soil prone to abrupt variations in soil water potential (sand/clay mix). Finally, such a model, explicitly coupling root system-soil water transfers, can be useful to study water uptake in relation with root architectural traits, distribution of root hydraulic conductance or influence of heterogeneous conditions (localised irrigation, root clumping).

View PDFchevron_right
Evaluation of root water uptake models – a review
Mahesh Jat

ISH Journal of Hydraulic Engineering, 2014

The accuracy of the Content should not be relied upon and should be independently verified with primary sources of information. Taylor and Francis shall not be liable for any losses, actions, claims, proceedings, demands, costs, expenses, damages, and other liabilities whatsoever or howsoever caused arising directly or indirectly in connection with, in relation to or arising out of the use of the Content. This article may be used for research, teaching, and private study purposes. Any substantial or systematic reproduction, redistribution, reselling, loan, sub-licensing, systematic supply, or distribution in any form to anyone is expressly forbidden.

View PDFchevron_right
A New Simulation Framework for Soil–Root Interaction, Evaporation, Root Growth, and Solute Transport
Holger Class

Vadose Zone Journal, 2018

We have developed a general model concept and a flexible software framework for the description of plant-scale soil-root interaction processes including the essential fluid mechanical processes in the vadose zone. The model was developed in the framework of non-isothermal, multiphase, multicomponent flow and transport in porous media. The software is an extension of the open-source porous media flow and transport simulator DuMu x to embedded mixed-dimensional coupled schemes. Our coupling concept allows us to describe all processes in a strongly coupled form and adapt the complexity of the governing equations in favor of either accuracy or computational efficiency. We have developed the necessary numerical tools to solve the strongly coupled nonlinear partial differential equation systems that arise with a locally mass conservative numerical scheme even in the context of evolving root architectures. We demonstrate the model concept and its features, discussing a virtual hydraulic lift experiment including evaporation, root tracer uptake on a locally refined grid, the simultaneous simulation of root growth and root water uptake, and an irrigation scenario comparing different models for flow in unsaturated soil. We have analyzed the impact of evaporation from soil on the soil water distribution around a single plant's root system. Moreover, we have shown that locally refined grids around the root system increase computational efficiency while maintaining accuracy. Finally, we demonstrate that the assumptions behind the Richards equation may be violated under certain conditions. Abbreviations: DUNE, Distributed Unified Numerics Environment; PDE, partial differential equation. Natural vegetation as well as cultivated crops play an important role in the global water budget, above and below the surface. Therefore understanding transpiration from vegetation is essential and has to be considered in land-atmosphere models used in climatology and hydrology. The interactions of water and plants need to be analyzed on a broad range of temporal and spatial scales (Fatichi et al., 2016), one of them focusing on the interaction of the root system of a single plant with the surrounding soil. Mathematical models and simulation of the relevant processes can help with the fundamental understanding of plants' reactions to their environment, how plant roots contribute to soil water distribution and flow or adapt to drought, or how they are influenced by soil water contamination or salinization (Shani and Ben-Gal, 2005). Although in situ monitoring methods of the physical processes at the soil-root interface are continuously being improved, measurements remain difficult (Zarebanadkouki et al., 2013). Mathematical models of coupled soil-root systems have been developed to study the transfer processes between the soil and root systems. Such models can also help in analyzing and interpreting measurements and the design of future experimental setups. Challenges include large differences in spatial and temporal scales and the combination of physical, chemical, and biological processes in a single model. Soil-root models range from single root segment models (Roose and Schnepf, 2008) for local soil-root interface studies, crop models used to predict yields (Malézieux et al., 2009), and models with empirical root uptake functions (Somma et al., 1998), to plant-scale models (Javaux et al., 2008) using Core Ideas • We present a locally mass-conservative flow, transport, and root-soil interaction model. • We include a sustainable, flexible research software framework for plant-scale model development. • This is an improved model concept for fluid dynamic processes, evaporation, root water uptake.

View PDFchevron_right
An empirical model for root water uptake
José Miguel Andriani

Soil water availability estimation is critical for assessing crop development and performance. During periods of soil water deficits, the capability of crop roots to extract soil water depends on the distribution and depth of its root system. Most water uptake models assume a relationship between root water extraction and root length density (RLD). However, models using RLD are difficult to test and several researchers have questioned the various proposed relationships between RLD and water uptake. A simplified water uptake model that does not use RLD was developed, but as an alternative, uses generalizations from measured soil water content changes to predict root water uptake. The daily incrementing model estimates a maximum water uptake rate by roots limited by soil water content that declines exponentially with the soil water content above the lower limit (LL) i.e., the remaining available soil water. The model assumes that: (i) the roots at a given layer have reached a minimum threshold of root density to extract water at a maximum rate; (ii) the transpiration demand is greater than the total root water uptake; and (iii) the water content at LL can be accurately measured or estimated. A critical constant (K) in the exponential model, representing the fraction of extractable water in a soil layer that can be taken up in 1 day, was found to be 0.096 for several species (cotton, maize, pearl millet, grain sorghum, soybean, sunflower and wheat), and different soil conditions. Values of K smaller than 0.096 were likely caused by root clumping in highly structured (cracking) or compacted soils, where root density was low in deeper soil layers when further downward root growth practically ceased, or by peanut whose K values was 0.064. This new empirical model should help to overcome several of the limitations of current models that rely on the use of measured or predicted RLD.

View PDFchevron_right
Simulating water uptake in the root zone with a microscopic-scale model of root extraction
Alain Perrier

Agronomie, 2003

Root water uptake is a key element for analysing the evolution of soil water content, which regulates crop transpiration. Our objective was to design a model taking into account the vertical water redistribution and the root water uptake in order to assess the regulation of plant transpiration induced by the effective soil water availability. To do so, the root water uptake is described with a microscopic-scale model integrated within a classical model of vertical water redistribution. For root water uptake, the root water potential, leading the water transfer from soil to roots, is calculated in order to satisfy the climatic demand... By coupling the microscopic and macroscopic approaches to soil water transfer, the regulation of transpiration can be directly linked to soil hydraulic properties and to effective soil water availability: the numerical model is applied to simulate soil water movement with root water uptake, and simulation results are compared with a series of findings on plant functioning obtained by previous work. Qualitatively, simulated transpiration in response to the soil water content is reasonably consistent with the description of crop behaviour in drying soils and in soil with vertical water heterogeneity. The results are also compared with experimental results in order to evaluate the usefulness of this model: with conventional measurements under field conditions, the prediction of water balance evolution is rather consistent with experimental results. model / root water uptake / soil-root transfer / transpiration / water Résumé-Simulation du prélèvement racinaire sur l'ensemble du système racinaire. Le prélèvement racinaire d'eau par les plantes est le point-clé pour l'analyse de l'évolution du contenu en eau du sol, lequel régule la transpiration des cultures. Notre objectif est de concevoir un modèle qui prenne en compte à la fois la redistribution verticale de l'eau dans le sol et à la fois le prélèvement racinaire pour évaluer les régulations de la plante induites par la disponibilité de l'eau du sol. Pour cela, le prélèvement racinaire qui est évalué par un modèle d'extraction racinaire décrivant les transferts sol-racine à l'échelle microscopique est couplé à un modèle de redistribution verticale de l'eau dans le sol. Grâce à ce couplage entre une approche microscopique et une approche macroscopique, la régulation de la transpiration est directement reliée aux propriétés de transfert d'eau du sol et à la disponibilité effective de l'eau pour le système racinaire. Les résultats des simulations sont mis en parallèle avec un ensemble de résultats expérimentaux caractérisant les réponses des plantes à une phase de dessèchement du sol. Qualitativement, les comportements de la plante vus sous l'angle de l'eau sont reproduits de manière satisfaisante pour un sol s'asséchant et pour un sol ayant un profl vertical d'humidité hétérogène. Les résultats du modèle sont également comparés avec des résultats expérimentaux obtenus dans les conditions naturelles. A partir de mesures classiques réalisées aux champs, l'évolution du bilan d'eau modélisée est très comparable à celle mesurée. modèle / prélèvement racinaire / transfert sol-racine / transpiration / eau

View PDFchevron_right
Use of a Three-Dimensional Detailed Modeling Approach for Predicting Root Water Uptake
Tom Schroder

Vadose Zone Journal, 2008

View PDFchevron_right
The impact of root data details on modelling of soil water transport in Soil-Plant-Atmosphere System
Willibald Loiskandl, Viliam Novak

The scope of the presented study is the role of plant roots in movement of water in soil - plant - atmosphere continuum and its modelling. The outcomes are product of long-term collaboration between the Institute of Hydraulics and Rural Water Management, BOKU Vienna and the Institute of Hydrology, Bratislava. In the frame of this cooperation, there were three joint missions conducted. During this research work, seasonal changes in root distributions profiles of three cereals crops grown on fields nearby Bratislava were determined. Next, an obtained range of root morphological parameter was applied for simulations of water uptake rate using own modelling tools. The results of root uptake conceptualization and the simulations showed the usefulness of this approach, but there was still a need for further development, in order to progress the model for specific applications in the field of root research. Handling with flexible root distribution function and uptake rate and compensatory ...

View PDFchevron_right
Validation of a root water uptake model to estimate transpiration constraints
D. Casaroli

Agricultural Water Management, 2010

Experimental results obtained from a greenhouse trial with common bean (Phaseolus vulgaris L.) plants performed to test model hypotheses regarding the onset of limiting hydraulic conditions and the shape of the transpiration reduction curve in the falling rate phase are presented. According to these hypotheses based on simulations with an upscaled single-root model, the matric flux potential at the onset of limiting hydraulic conditions is as a function of root length density and potential transpiration rate, while the relative transpiration in the falling rate phase equals the relative matric flux potential. Transpiration of bean plants in water stressed pots with four different soils was determined daily by weighing and compared to values obtained from non-stressed pots. This procedure allowed determining the onset of the falling rate phase and corresponding soil hydraulic conditions. At the onset of the falling rate phase, the value of matric flux potential M l showed to differ in order of magnitude from the model predicted value for three out of four soils. This difference between model and experiment can be explained by the heterogeneity of the root distribution which is not considered by the model. An empirical factor to deal with this heterogeneity should be included in the model to improve predictions. Comparing the predictions of relative transpiration in the falling rate phase using a linear shape with water content, pressure head or matric flux potential, the matric flux potential based reduction function, in agreement with the hypothesis, showed the best performance, while the pressure head based equation resulted in the highest deviations between observed and predicted values of relative transpiration rates.

View PDFchevron_right

References (33)
